Amana Tools 82-Degree Carbide Tipped Countersink, 1/2-in. Diameter x 3/16-in. Drill Diameter x 1/4-in. Shank for Festool CENTROTEC System (55338)
Amana Tools 82-Degree Carbide Tipped Countersink, 1/2-in. Diameter x 3/16-in. Drill Diameter x 1/4-in. Shank for Festool CENTROTEC System (55338)
Out of Stock - Available to Order - Usually ships in 17-22 days
Product Details
Product Details
Key Features
Overview
The Amana Tools 55338 Carbide Tipped 82 Degree Countersink is a countersink bit built for drilling a pilot hole and cutting an 82 degree countersink for wood screws in one pass. This is a countersink designed for fast, repeatable screw-hole prep in woodworking and finish work. Model 55338 uses a 1/2 inch countersink diameter, a 3/16 inch drill diameter, and a 1/4 inch quick-release hex shank for users who want cleaner results and less time spent changing bits.
What makes this setup useful on the bench or on site is the adjustable depth stop with a no-thrust ball bearing. That matters because the stop rides the work without scratching or burning the surface while giving you a more repeatable finished depth. If you are running rows of screws in cabinetry, trim, furniture parts, or shop-built jigs, consistent countersink depth is the difference between a clean finished job and one that looks pieced together.
Amana builds this countersink with a carbide-tipped cutter and includes a slow spiral, fully ground HSS M2 drill bit. In plain terms, you get the wear resistance of carbide where the countersink is doing the cutting and a proper pilot drill matched to the tool. The open design also gives chips a place to clear out, which helps the bit cut cleaner instead of packing up in the hole.
The hybrid shank is another practical detail. It is shaped to fit Festool CENTROTEC drill machines, but it also works in standard quick-change chucks for 1/4 inch hex shanks. If your drill setup changes from the shop to the truck, you are not locked into one interface. That makes this countersink bit easier to keep in rotation across different fastening and drilling setups.
This countersink bit is sized for wood screw #16 and is intended for a broad range of materials including natural woods, man-made boards, MDF, chipboard, plywood, composites, composite decking materials, HDPE, acrylic, aluminum, and other non-ferrous materials. That wider material range matters if your work moves between hardwood parts, sheet goods, plastic trim, and specialty panels. One tool can cover a lot of hole-prep work without swapping to a separate dedicated setup for every material.
From a usability standpoint, the design lets you control drill length and replace the drill bit without taking the depth stop apart. That saves time when the bit needs service and makes this style of countersink less annoying to maintain than older designs that require a full teardown just to make a simple adjustment. The heavy-duty revolving stop collar also helps protect the workpiece when you are working on visible faces.
If you do cabinetry, furniture work, finish carpentry, general woodworking, or installation work where screw heads need to sit clean and flush, this is the kind of countersink that earns its spot fast. It is especially useful for users already on the Festool CENTROTEC system, but the standard quick-release hex fit keeps it practical for anyone using common drill and driver setups. If your goal is faster screw prep with better surface protection, this bit makes a strong case.
Clean Countersinks Without Surface Damage
This countersink bit is built to help you cut repeatable screw seats while being easier on the workpiece. The revolving no-thrust ball bearing depth stop is there for one reason: keep the stop moving against the surface instead of dragging and marking it.
- 82 degree countersink profile for wood screw seating
- Adjustable heavy-duty depth stop for fast depth changes
- Open area around the cutter helps chip evacuation
What's in the Box
- (1) Amana Tools 55338 carbide tipped 82 degree countersink assembly
- (1) Slow spiral HSS M2 fully ground drill bit
Key Specifications
| Angle | 82° |
|---|---|
| Countersink Diameter | 1/2 in. |
| Drill Diameter | 3/16 in. |
| Shank Size | 1/4 in. quick-release hex |
| Overall Length | 2-3/4 in. |
| Cutting Height | 3/64 in. to 3/8 in. |
| Wood Screw Size | #16 |
| Drill Bit Type | Slow spiral HSS M2 fully ground |
Compatibility
Built For
Pro Tip
When you use this countersink on aluminum or other non-ferrous material, slow the drill down, skip the vacuum, and use lubricant or air cooling. You will get a cleaner hole and better life out of the cutter.
Tool Nut's Take
Amana Tools 55338 Carbide Tipped 82 Degree Countersink for Clean, Repeatable Screw Prep
This is a smart pick for anyone who wants one-step pilot drilling and countersinking with better depth control and less chance of marring the surface.
- Who it's for: Woodworkers, cabinet guys, finish carpenters, and installers who want neat screw holes in visible work.
- Why it stands out: The hybrid Festool CENTROTEC and 1/4 inch hex fit is genuinely useful, and the no-thrust bearing stop is the feature that makes this one more than just another countersink bit.
- Worth knowing: It is sized for #16 wood screws, so make sure that matches your fastening work before you buy.
Common Questions
- What type of chuck does this countersink fit? It fits Festool CENTROTEC drill machines and also standard 1/4 inch hex quick-change chucks.
- Can it drill and countersink in one step? Yes. The tool is designed to drill the pilot hole and cut the tapered countersink in one operation.
- What materials can it be used on? It is listed for natural woods, man-made boards, MDF, chipboard, plywood, composites, composite decking, HDPE, acrylic, aluminum, and other non-ferrous materials.
- Is the drill bit replaceable? Yes. The listed replacement drill is Amana 630-236.
