DeWALT DCG422B 20V MAX ATOMIC Right Angle Die Grinder 3.5Ah POWERSTACK Kit
DeWALT DCG422B 20V MAX ATOMIC Right Angle Die Grinder 3.5Ah POWERSTACK Kit
In Stock - Ready to Ship
Product Details
Product Details
Key Features
Overview
The DeWALT DCG422B 20V MAX ATOMIC Right Angle Die Grinder 3.5Ah POWERSTACK Kit combines the compact ATOMIC right angle die grinder with a DCBP320C XR POWERSTACK 3.5Ah battery and charger starter kit. This is a cordless right angle die grinder designed for grinding, deburring, weld cleanup, and surface prep in tight spaces. Model Number DCG422B-PROMO DCBP320C. It is built for automotive techs, fabricators, welders, and maintenance crews who want to stop dragging an air hose to every job.
The numbers that matter are speed and output. The brushless motor runs up to 24,500 RPM no-load through a variable speed trigger, and DEWALT rates the tool at up to 455 MWO (max watts out). DEWALT also rates it at up to 53% more power than a 0.4 HP pneumatic right angle die grinder. In practice that means steady cutting and blending on welds, brackets, and exhaust work without waiting on a compressor to recover.
Control is where this grinder earns its place. The ANTI-ROTATION System shuts the wheel down when it detects a pinch, stall, or bind-up, and the switch must be cycled off and on to restart. An electronic brake is designed to stop the wheel in less than 1 second after you release the trigger, so you can move between grinding points without waiting for the accessory to spin down. A paddle switch with lock-off and no-lock-on rounds out the safety package. When the job calls for reaching straight into a port or bore, a straight-body model from the DeWALT die grinders range is the better fit; for corners and undersides, the right angle head wins.
The ATOMIC body is all about access. DEWALT gave it a gripping diameter equal to a low-voltage cordless die grinder and rates it 9% shorter in use than a comparable pneumatic model, which helps when you are working under a vehicle or inside a frame. The glass-filled nylon housing resists oils and harmful solvents, a forward exhaust keeps air off your hand, and an onboard LED lights the work. Wheel changes go quickly with the spindle lock and 1/4" collet.
What separates this kit from the tool-only version is the battery. The included DCBP320 20V MAX XR POWERSTACK 3.5Ah battery uses pouch cell construction instead of cylindrical cells. DEWALT rates it at up to 50% more power than its DCB205 5Ah battery in a more compact package, with longer lifespan, an overmolded impact-resistant base, and an LED state-of-charge gauge. On a small grinder, that compact pack keeps the tool balanced and short enough to reach where it needs to go.
The grinder and battery both run on the DEWALT 20V MAX platform, so the pack works with the rest of your 20V MAX tools and chargers. The tool is also TOOL CONNECT Chip Ready; add the chip (sold separately) and the DEWALT TOOL CONNECT app for asset management and tool location tracking across a crew.
Who should buy it? Automotive and fleet technicians, welders, fabricators, and maintenance techs who need a right angle die grinder for close work and do not already have a spare 20V MAX battery and charger. If you already own several packs, the tool-only grinder makes more sense. If you are starting fresh on DeWALT 20V MAX tools or adding a dedicated pack to a service truck, this kit covers everything in one box.
Get Into the Tight Spots
Under a lift or inside a frame, a bulky grinder or an air hose is the problem. The ATOMIC right angle head keeps the tool small where the work is.
- Gripping diameter equal to a low-voltage cordless die grinder
- Rated 9% shorter in use than a comparable pneumatic die grinder
See the Work, Stop the Wheel
The onboard LED lights dark corners under vehicles and inside cabinets, and the electronic brake stops the wheel fast when you let off the trigger.
- Electronic brake designed to stop the wheel in less than 1 second
- Forward exhaust directs air away from your hand
Compact Power for Weld Cleanup
Blend welds, clean up edges, and prep surfaces with a variable speed trigger that lets you ease in on delicate work and open it up for stock removal.
- Up to 24,500 RPM no-load speed
- Spindle lock and 1/4" collet for quick accessory changes
What's in the Box
- (1) DCG422 ATOMIC 20V MAX Right Angle Die Grinder
- (1) 1/4" Collet
- (1) Wrench
- (1) DCBP320 20V MAX XR POWERSTACK 3.5Ah Battery
- (1) DCB1104 12V/20V MAX Charger
Grinding wheels, burrs, and discs are sold separately.
Key Specifications
|
|
20V MAX (18V nominal) |
|---|---|
|
|
0 to 24,500 RPM |
|
|
Up to 455 MWO |
|
|
Brushless |
|
|
1/4" |
|
|
3.5Ah XR POWERSTACK |
|
|
Yes, stops wheel in under 1 second |
|
|
2.6 lbs (tool only) |
Compatibility
Built For
Pro Tip
If the grinder stops mid-cut after a bind-up, it has not died. The ANTI-ROTATION System has tripped. Release the paddle, cycle the switch off and back on, and reset your angle before you dig back in.
Warranty & Support
Tool Nut's Take
The DeWALT DCG422B 20V MAX ATOMIC Right Angle Die Grinder 3.5Ah POWERSTACK Kit Cuts the Hose
A compact die grinder only makes sense if the battery keeps it compact, and the POWERSTACK pack does exactly that.
- Who it's for: Auto techs, welders, fabricators, and maintenance crews who need a right angle die grinder and do not have a spare 20V MAX battery and charger.
- Why it stands out: ANTI-ROTATION protection, a sub-1-second brake, and 24,500 RPM in an ATOMIC-size body, paired with DEWALT's pouch-cell XR battery.
- Worth knowing: This is a die grinder for access and finesse, not a replacement for a 4-1/2" angle grinder on heavy stock removal. Wheels and burrs are not included.
Common Questions
- Does this kit include a battery and charger? Yes. It includes one DCBP320 20V MAX XR POWERSTACK 3.5Ah battery and one DCB1104 charger.
- How fast does it spin? Up to 24,500 RPM no-load, with a variable speed trigger.
- Why did the grinder shut off during a cut? The ANTI-ROTATION System stops the wheel on a pinch, stall, or bind-up. Cycle the switch off and on to restart.
- Will other 20V MAX batteries work? Yes. The grinder runs on DEWALT 20V MAX batteries.
