Makita 40V max XGT Brushless 5-in. Paddle Switch Flathead Grinder, Variable Speed, with Electric Brake, Tool Only (GAG16Z)
Makita 40V max XGT Brushless 5-in. Paddle Switch Flathead Grinder, Variable Speed, with Electric Brake, Tool Only (GAG16Z)
Out of Stock - Available to Order - Usually ships in 12-18 days
Product Details
Product Details
Key Features
Overview
The Makita GAG16Z 40V max XGT Brushless Cordless 5" Paddle Switch Flathead Grinder is a cordless flathead grinder built for grinding and cutting in places where a standard grinder body gets in the way. This is a flathead grinder designed for metal grinding, cut-off work, and access-sensitive fabrication tasks. Model Number: GAG16Z. If you work around pipe, railings, frames, weld seams, or other tight-clearance areas, this tool is built to solve a real access problem without giving up the power you expect from a serious grinder.
Makita built this model on the 40V max XGT platform and rates it to deliver the power of a 13 amp corded grinder. On the job, that means you get cordless mobility without stepping too far back in performance for heavier work. The variable 5-speed control dial gives you five fixed speed settings at 3,000, 4,500, 6,000, 7,500, and 9,000 RPM, so you can match wheel speed to the material and the task. That is useful when you want more control for finishing passes, deburring, or cut-off work, and still have the top-end speed for aggressive grinding.
The big story here is the low-profile 39 degree flathead design. Makita says it provides over 45% more access in tight spaces, and that is the feature that separates this tool from a standard cordless angle grinder. For metalworking, welding cleanup, and maintenance work, getting the wheel into cramped corners or between obstructions often matters more than raw speed on paper. This grinder is designed around that real-world need.
Makita also paid attention to everyday usability. The paddle switch gives convenient on and off control, and the lock-off function helps prevent accidental startup. The tool-less wheel guard speeds up guard changes and position adjustments, which saves time when you move between grinding and cut-off setups. An electric brake adds productivity and control by bringing the wheel down faster after you release the switch.
For protection, the GAG16Z includes Active Feedback-sensing Technology, which shuts the motor off if the wheel rotation is suddenly forced to stop. That is the kind of feature you appreciate when a wheel binds or the tool gets loaded unexpectedly. Anti-restart protection helps prevent the motor from starting when a battery is installed with the switch engaged. An electronic current limiter helps protect the motor during high-torque applications, and Extreme Protection Technology is engineered for improved dust and water resistance in rough jobsite conditions.
This grinder uses a Makita-built brushless motor and is part of the Makita 40V max XGT system. XGT tools and batteries use digital communication to optimize performance and monitor overload, over-discharge, and overheating. If you are already on XGT, this is an easy fit. If you are building out a high-demand cordless platform for fabrication, construction, plant maintenance, or mobile service work, this tool makes a strong case because it is aimed at heavier-duty cordless use instead of light trim work.
It runs 5 inch wheels and uses a 5/8 inch - 11 UNC spindle, which is a common setup for grinder accessories in this class. The overall length is 16-3/4 inches, and the listed net weight with battery is 9.88 pounds. That tells you right away this is not meant to be a tiny cutoff toy. It is a full-size cordless grinder designed to reach awkward spots while still handling real work.
Who should buy it? Metal fabricators, welders, ironworkers, mechanical contractors, maintenance crews, and serious contractors who regularly deal with tight working clearances. If your current grinder has plenty of power but not enough access, this model fixes that. If you mostly do open-area grinding and want the lightest tool possible, a standard grinder may make more sense. But if access is the bottleneck, the GAG16Z is the kind of specialty tool that earns its place fast.
Reach Tight Grinding Areas
This is the reason to buy this tool. The flathead layout gives you better approach angles when grinding or cutting in spaces blocked by pipe, framing, brackets, or welded assemblies.
- 39 degree low-profile flathead design for improved access
- Over 45% more access in tight spaces compared to standard grinder layouts
- 5 inch wheel capacity for common grinding and cut-off tasks
Control Speed for the Material
Not every grinding job wants maximum speed. The 5-step speed dial gives you better control for cleanup work, edge prep, and cut-off applications where too much speed can make the tool harder to manage.
- Five speed settings: 3,000 / 4,500 / 6,000 / 7,500 / 9,000 RPM
- Brushless motor built for high-demand cordless performance
- Paddle switch with lock-off for controlled start and stop
Built for Real Jobsite Conditions
This grinder is not just about access. Makita added the protection and convenience features that matter when the tool gets used hard and often.
- Electric brake helps reduce downtime between cuts and grinding passes
- Active Feedback-sensing Technology shuts the motor off if the wheel is suddenly forced to stop
- Extreme Protection Technology is engineered for improved dust and water resistance
What's in the Box
- (1) Makita GAG16Z 40V max XGT Brushless Cordless 5 inch Paddle Switch Flathead Grinder
- (1) 5 inch Tool-Less Wheel Guard
- (1) 5 inch Tool-Less Cut-Off Wheel Guard
- (1) Inner Flange
- (1) Lock Nut
- (1) Side Handle
- (1) Side Handle Adapter
Grinding wheel, battery, and charger are not included.
Key Specifications
| Wheel Diameter | 5 in |
|---|---|
| No-Load Speed (RPM) | 3,000 / 4,500 / 6,000 / 7,500 / 9,000 RPM |
| Spindle Thread Size | 5/8 in - 11 UNC |
| Power Source | Cordless |
| Motor Type | Brushless |
| System | Makita 40V max XGT |
| Overall Length | 16-3/4 in |
| Net Weight (with battery) | 9.88 lbs |
Compatibility
Built For
Pro Tip
If you are using the GAG16Z for mixed grinding and cut-off work, keep both tool-less guards set up and swap as the job changes instead of forcing one setup to do everything. That saves time and makes the flathead design easier to take advantage of in cramped spots.
Warranty & Support
Tool Nut's Take
Makita GAG16Z 40V max XGT Brushless Cordless 5" Paddle Switch Flathead Grinder That Solves a Real Problem
This is the kind of specialty grinder that makes perfect sense the first time a standard grinder cannot physically reach the work.
- Who it's for: Welders, fabricators, maintenance crews, and contractors who regularly grind or cut in cramped locations.
- Why it stands out: The flathead design is the headline, but the variable speed range, electric brake, brushless motor, and XGT power system are what make it feel like a serious daily-use tool instead of a niche add-on.
- Worth knowing: This is a bare tool, so battery and charger are extra, and it is best suited to buyers who actually need the extra access a flathead grinder provides.
Common Questions
- What battery platform does this grinder use? It is compatible with Makita 40V max XGT Lithium-Ion batteries.
- What size wheel does it use? This grinder is designed for 5 inch wheels.
- Does it have variable speed? Yes. It has a 5-speed dial with settings from 3,000 to 9,000 RPM.
- Does it include a battery or charger? No. This is a tool-only version.
- Does it have a brake? Yes. It includes an electric brake for faster wheel stop.
