The Simpson Strong-Tie ECC5 1/4-6 ECC End Column Cap is a structural end column cap for connecting a 5-1/8 in. beam to a 6x post in wood construction. This is a column cap designed for wood-to-wood end-of-beam connections. Model Number: ECC5 1/4-6. If you are building a post-and-beam connection and need a connector that carries real load while keeping bolt placement consistent, this is the kind of hardware you spec instead of trying to piece together a field-made solution.
What sets the ECC series apart is the extended seat. That seat gives the beam more bearing area, which helps distribute load more widely through the connection. On this specific model, Simpson lists an allowable download of 17,615 lb, so this is clearly aimed at structural framing where the connector is doing more than just holding alignment. It is built for end-of-beam applications, meaning it is intended to support and secure the beam at the top of the post rather than acting like a light bracket or trim connector.
The steel build matters here too. The ECC5 1/4-6 is made from 3-gauge steel and uses certified welds, which is exactly what you want in a heavily loaded structural connector. In plain terms, that means confidence in the connection where the seat and straps work together to resist load. Simpson also calls out increased uplift loads for earthquake or wind loading, which is important when the connection needs to do more than just hold downward weight.
Installation details are practical and specific. This model uses 3/4 in. bolts, with 2 beam bolts and 2 post bolts. Simpson specifies that bolt holes should be drilled from one side all the way through the beam to maintain hole tolerances, and the bolt holes should be between 1/32 in. and 1/16 in. larger than the bolt diameter per NDS guidance. That is the sort of detail that makes a difference on a structural connection, because sloppy hole prep can undermine fit and load performance.
The connector also includes diamond holes for temporary fastening. That is a small feature, but on the job it helps with positioning before final bolting, especially when you are holding beam and post alignment during layout and assembly. The finish is Simpson Strong-Tie gray paint, which is the standard finish listed for this product family.
In terms of sizing, this ECC model is set up around a 5-1/8 in. beam width with key dimensions of 5-1/4 in. W1, 5-1/2 in. W2, 10-1/2 in. L, and 8-1/8 in. H1. Those numbers are what make this a specific fit, not a universal bracket. If your beam and post sizes match the connector, you get the benefit of a purpose-built post cap with known geometry and published load data.
This is a good fit for builders, framers, timber and post-frame crews, and contractors working on structural wood framing where a code-conscious post-to-beam connector is required. If you need a clean, engineered way to fasten a beam to a 6x post at the end condition, the Simpson Strong-Tie ECC5 1/4-6 ECC End Column Cap is the right kind of hardware. If your beam width or post size differs, you should step into the correct ECC model instead of trying to make this one work.
Spreads Load Where It Counts
The extended seat is the whole point of this connector. It gives the beam better bearing support at the post connection, which helps manage structural loads more effectively in end-of-beam applications.
- Designed specifically for wood-to-wood fastening
- Allowable download for this model is 17,615 lb
Made for Real Structural Fastening
This is not light-duty hardware. The 3-gauge steel body and certified welds are there for one reason: dependable structural performance where the beam meets the post.
- 3-gauge steel construction for the ECC5 1/4-6 model
- Certified welds for strength and load confidence
Cleaner Layout, Less Guesswork
Good structural hardware should help the installer, not slow the job down. NDS-compliant bolt spacing and diamond holes for temporary fastening make it easier to position the connector accurately before final bolting.
- Uses 3/4 in. bolts
- Diamond holes assist with temporary fastening during setup
Key Specifications
| Application | Wood-to-Wood |
|---|---|
| Material | 3-gauge steel |
| Finish | Simpson Strong-Tie gray paint |
| Beam Width | 5-1/8 in. |
| W1 | 5-1/4 in. |
| W2 | 5-1/2 in. |
| Length (L) | 10-1/2 in. |
| Height (H1) | 8-1/8 in. |
| Bolt Size | 3/4 in. |
| Beam Bolt Quantity | 2 |
| Post Bolt Quantity | 2 |
| Allowable Download | 17,615 lb |
Compatibility
Built For
Pro Tip
Drill the bolt holes from one side all the way through the beam instead of meeting in the middle. That helps keep the hole alignment and tolerance where Simpson wants it, which makes bolting easier and protects connection performance.
Tool Nut's Take
Simpson Strong-Tie ECC5 1/4-6 ECC End Column Cap Means You Stop Improvising Structural Connections
This is the right pick when you need a real engineered post cap for a 5-1/8 in. beam to 6x post connection and do not want to trust a built-on-site workaround.
- Who it's for: Contractors, framers, and builders handling structural wood connections where published load data and correct geometry matter.
- Why it stands out: The extended seat, certified welds, 3-gauge steel build, and 17,615 lb allowable download make it more than just a bracket.
- Worth knowing: This is a size-specific connector. Match the beam and post dimensions correctly, and follow the specified bolt and hole requirements.
Common Questions
- What is this connector used for? It is used for end-of-beam applications in wood construction where a beam connects to the top of a post.
- What size beam does the ECC5 1/4-6 fit? This model is designed for a 5-1/8 in. beam width.
- What size post is it intended for? It is configured for a 6x post connection.
- What bolt size does it use? Simpson lists this model for 3/4 in. bolts, with two bolts at the beam and two at the post.
- Does it help with uplift as well as downward load? Yes. Simpson states that uplift loads are increased for earthquake or wind loading.
